RS-390PH high quality high speed 6v dc electric motors

Product Description

High quality round shape mini 6v dc electric motors.

Mini DC Low Voltage Motor Model No. RS-390PH-4532R.

The motor belong to the customization, need more specifications, pls contact us!

Introduction

20 years' motor design and production experience
90 million-piece annual capacity
Auto motors are almost entirely produced on automated lines
Facilities certified to IAFT16949:2016,ISO 9001:2008 and ISO 14001:2004
Advanced equipment from Sodick, Hexagon,Mitutoyo, Magtrol and Votsch
10% sales revenue invested in R&D and automatic equipment every year
Customer PPM: auto motors s 30;general motors s 3,000

Product Description

 Mini 6v DC motor Product Specification:

  • MEASURING CONDITIONS:
  1. Rated Voltage: DC 6.0 V
  2. Environmental temperature: +5 °C - +35°C
  3. Environmental humidity: 40%-85%RH
  4. Motor Position: Motor to be held with shaft horizontally.
  • ELECTRICAL CHARACTERISTICS (At initial stage after 30 seconds run-in)
  • No load Speed: 12800 ±10%rpm
  • No load Current:<0.6A
  • On load Speed: 11050 ±10%rpm
  • On load Torque: 150g.cm
  • On load current: <5.6A
  • Stall Torque: 1100g.cm
  • Stall current: ≤ 24A
  • Direction of Rotation: CW when viewing motor output side with positive voltage applied to positive(red) terminal.

         Note: (1).The above performance are customized from clients just for you reference.

                    (2).Unit Conversion: 1g.cm≈0.098mN.m≈0.014oz.in 1mm=0.039in 1g=0.035oz.

                    (3). Customized electric performance on request by using suitable DC Motor windings and ratio.





Mini 6v dc motor Product Outline:



     Note:1.Motor housing length 46.5m, and max diameter 27.7mm;

               2."B" stand for customized output shaft length including the step height;

               3.Need other size about output shaft length and diameter can be custom made.







Mini 6v dc motor Basic Features:

  • Carbon Steel Shaft
  • Plastic End Cap
  • Sintered Bronze Bearing
  • Leaf Brush System
  • 3Slots/5Slots Armature
  • With Flux Ring
  • EMC/EMI Suppression
Application

More DC motors

Kinmore  The most complete DC motor supplier.

Company Information


Certificate


FAQ

Q:1.What kind of motors you can provide?

A: For now, we mainly provide permanent magnet brushed dc motors (including vibration motors, low voltage dc motors and high voltage dc motors) with diameter range in 6~80mm and also Dia10~80mm size gear motors.

Q:2. Can you send me a price list?

A: For all of our motors, they are customized based on different requirements like lifetime, noise, voltage, and shaft etc. The price also varies according to annual quantity. So it's really difficult for us to provide a price list. If you can share your detailed requirements and annual quantity, we'll see what offer we can provide.

Q:3. What's the lead time for regular order?

A: For orders, the standard lead time is 35-40 days and this time can be shorter or longer based on different model, period and quantity.

Q:4. Is it possible for you to develop new motors if we can provide tooling cost?

A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we'll make our evaluation to see if we can arrange or not.

Q:5. Can I get some samples?

A: It depends. If only a few samples for personal use or replacement, I am afraid it'll be difficult for us to provide because all of our motors are custom made and no stock available if there is no further needs. If just sample testing before the official order and our MOQ, price and other terms are acceptable, we'd love to provide samples.



Contact us if you need more details on 6v Dc Electric Motors. We are ready to answer your questions on packaging, logistics, certification or any other aspects about 6 Volt Dc Electric Motor、6v Dc Mini Motors. If these products fail to match your need, please contact us and we would like to provide relevant information.
