120-240v electric brushed motor

Product Description

120-240v electric brushed motor



Product Description





MODEL         VOLTAGE    AT NO LOAD              AT MAXIMUM EFFICIENCY          AT STALL
RANGE NOMINAL SPEED CURRENT SPEED CURRENT TORQUE OUTPUT EFF. CURRENT TORQUE
V V rpm A rpm A g.cm W % A g.cm
RS-7512SH-11226L AC Full Wave Rectifying  230 CONST 13000 0.11 9820 0.33 615 61.96 64.08 1.01 2512
RS-7512SH-08400R AC Full Wav Rectifying  240 CONST 6450 0.028 5337 0.13 414 22.67 57.08 0.62 2400
RS-7512SH-08310R AC Full Wave Rectifying  220 CONST 6500 0.028 5449 0.14 456 25.49 65.03 0.72 2820
RS-7512SHF-11160R AC Full Wave Rectifying  120 CONST 9500 0.09 7388 0.31 472 35.78 75.44 1.08 2123
Unit Conversion: 1g.cm≈0.098mN.m≈0.014oz.in   1mm=0.039in   1g=0.035oz



Related Items

All types DC motor can be customized

For all of automotive motors are almost entirely produced by automated lines. We bring in many advanced inspection facilities to improve our quality control ability and now our customer PPM is no more than 30. We utilize 110-plus testing devices , FMEA and PPAP, administer a battery of tests including material incoming test, 100% inspection on line, packing vibration and outgoing inspection before delivery as well as our motors are RoHs/Reach/CE compliant.The motor widely used for Automotive, Home Appliance, Personal Care, Power tools, Industry.

Company Information


FAQ

Q:1.What kind of motors you can provide?

A: For now, we mainly provide permanent magnet brushed dc motors (including vibration motors, low voltage dc motors and high voltage dc motors) with diameter range in 6~80mm and also Dia10~80mm size gear motors.

Q:2. Can you send me a price list?

A: For all of our motors, they are customized based on different requirements like lifetime, noise, voltage, and shaft etc. The price also varies according to annual quantity. So it's really difficult for us to provide a price list. If you can share your detailed requirements and annual quantity, we'll see what offer we can provide.

Q:3. What's the lead time for regular order?

A: For orders, the standard lead time is 35-40 days and this time can be shorter or longer based on different model, period and quantity.

Q:4. Is it possible for you to develop new motors if we can provide tooling cost?

A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we'll make our evaluation to see if we can arrange or not.

Q:5. Can I get some samples?

A: It depends. If only a few samples for personal use or replacement, I am afraid it'll be difficult for us to provide because all of our motors are custom made and no stock available if there is no further needs. If just sample testing before the official order and our MOQ, price and other terms are acceptable, we'd love to provide samples.






Contact us if you need more details on Electric Motor. We are ready to answer your questions on packaging, logistics, certification or any other aspects about 240v Electric Motors、Brushed Motor. If these products fail to match your need, please contact us and we would like to provide relevant information.
